Paper Cup Forming Machine

The paper cup forming machine is an automatic equipment with multi-stations, cam and chain transmission. This paper cup forming machine can finish the whole operations including paper feeding, oil casting, bottom punching, heating, knurling, edge curling and cups removing.
This paper cup forming machine is an ideal machine for manufacturing teacup, advertisement cup, ice cream cup, coffee cup, etc.

Note:
If you want to manufacture the single PE coated paper cups, please use the DB-C16 ,DB-C18 ,DB-C22 paper cup forming machines, if make the double PE coated paper cups, we recommend the DB-2C16, DB-2C18,DB-2C22 paper cup forming machines.

Main Parameters of DB-C16 Paper Cup Forming Machine:

Type	DB-C16	DB-2C16	DB-C18	DB-2C18	DB-C22	DB-2C22
Capacity	45-55pcs/ min		40-50pcs/ min		30-40pcs/ min
Required paper thickness	150-250gsm one-side PE coated paper	150-380gsm two-side PE coated paper	150-250gsm one-side PE coated paper	150-380gsm two-side PE coated paper	150-250gsm one-side PE coated paper	150-380gsm two-side PE coated paper
Paper cup specification	(A)ф50-90mm,(B) 45-100mm, (C)ф35-75mm,(D) 4.5-10mm.		(Aф)60-128mm,(B) 45-140mm, (C)ф50-97mm,(D) 4.5-10mm.		(A)ф60-128mm,(B) 45-180mm, (C)ф50-97mm,(D) 4.5-10mm.
Required air supply	Working Pressure: 0.4-0.6Mpa Working Gas: 0.5m3 /minute
Total power	220V 50Hz 3.8kW or 380 V 50 Hz 3.8kW (variable-frequency control)
Weight	1300kg		1550kg		1600kg
Dimension (L×W×H)	2450×1200×1750mm		2450×1200×1800mm		2700×1300×2000mm

The Size of the Available Paper Cups/Bowls


Processing Flow Chart
